SAILOR 7222 VHF DSC Class A

Add to quote
Category: Tags: , , ,

Highly resilient and easy to operate in any situation, the SAILOR 7222 VHF DSC Class A is the most advanced SAILOR radio for demanding users operating within the SOLAS maritime environment. As a next generation solution at the forefront of radio technology, it unlocks new performance gains that improve critical safety and regular operational communication.

Description

Weight 1.5 kg (3.3 lbs)
Dimensions HxWxD: 161 x 306 x 51 mm
Operating temperatures -15°C to +55°C
Storage temperature -25°C to +70°C
Ingress protection IPX2
Power supply 24 VDC +30%/-10%
Power consumption (typical) Rx operative: 8 W
Tx 25 W operative: 65 WTx 1 W operative: 18 W
Heat dissipation (typical) Rx operative: 8 W
Tx 25 W operative: 40 WTx 1 W operative: 17 W
Rx/Tx ant. input/output 50 ohm @ Tx voice/Tc DSC & Rx voice
DSC ant. input 50 ohm @ Rx DSC
LAN 2 LAN ports category 6 STP
Frequency range Voice: 156.000 MHz — 164.000 MHz

DSC: 156.525 MHz
Channel spacing 25 kHz, all international maritime channels
Number of P channels The radio may be programmed with up to 100 private channels in all channel
Modulation 16K0G3E, 16KOG2B (DSC)
